MC74HC4066D - Motorola

Description: High Performance Silicon-Gate MOS

Download MC74HC4066D Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MC74HC4066D - Motorola PCB footprint - Small Outline Packages - Small Outline Packages - D SUFFIX PLASTIC SOIC PACKAGE CASE 751A–03 ISSUE F
click to zoom
3D Models
MC74HC4066D - Motorola  - 3D model - Small Outline Packages - D SUFFIX PLASTIC SOIC PACKAGE CASE 751A–03 ISSUE F
click to zoom

MC74HC4066D Details

  • Manufacturer Part Number:

    MC74HC4066D

  • Part Life Cycle Code:

    Transferred

  • Package Description:

    0.150 INCH, PLASTIC, SOIC-14

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Motorola Semiconductor Products

  • Analog IC - Other Type:

    SPST

  • JESD-30 Code:

    R-PDSO-G14

  • JESD-609 Code:

    e0

  • Length:

    8.65 mm

  • Normal Position:

    NO

  • Number of Channels:

    1

  • Number of Functions:

    4

  • Number of Terminals:

    14

  • Off-state Isolation-Nom:

    40 dB

  • On-state Resistance Match-Nom:

    20 Ω

  • On-state Resistance-Max (Ron):

    130 Ω

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -55 °C

  • Output:

    SEPARATE OUTPUT

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP14,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.75 mm

  • Supply Current-Max (Isup):

    0.16 mA

  • Supply Voltage-Nom (Vsup):

    12 V

  • Surface Mount:

    YES

  • Switch-off Time-Max:

    15 ns

  • Switch-on Time-Max:

    15 ns

  • Switching:

    MAKE-BEFORE-BREAK

  • Technology:

    CMOS

  • Temperature Grade:

    MILITARY

  • Terminal Finish:

    Tin/Lead (Sn/Pb)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Width:

    3.9 mm

MC74HC4066D Frequently Asked Questions (FAQs)

  • The maximum frequency of operation for the MC74HC4066D is typically around 10 MHz, but it can vary depending on the specific application and operating conditions.
  • To ensure proper switching times, it's essential to provide a clean and stable clock signal, and to minimize the capacitive load on the switch outputs. Additionally, the switch control inputs should be driven with a low-impedance source to minimize rise and fall times.
  • The maximum voltage rating for the analog switches is ±15V, but it's recommended to operate within the specified voltage range of VCC to minimize power consumption and ensure reliable operation.
  • While the MC74HC4066D is primarily designed as an analog switch, it can be used as a digital switch in certain applications. However, it's essential to ensure that the digital signal levels are within the specified voltage range and that the switch control inputs are properly driven to avoid signal degradation.
  • To minimize power consumption, operate the device at the lowest possible voltage, reduce the clock frequency, and minimize the capacitive load on the switch outputs. Additionally, consider using a lower-power alternative, such as the MC74HCT4066D, if possible.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

MC74HC4066D Overview

Use the download button to access the MC74HC4066D schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like MC74H, or try a keyword search, such as Multiplexers or Switches
