MCDHN-04F-V - Multicomp Pro

MCDHN-04F-V Details

• Manufacturer Part Number:

  MCDHN-04F-V

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  SPC Multicomp

• YTEOL:

  8

• Actuator Color:

  WHITE

• Actuator Type:

  SLIDE TYPE

• Body Breadth:

  4.5 mm

• Body Color:

  BLACK

• Body Height:

  1.5 mm

• Body Length or Diameter:

  6.31 mm

• Center Contact Material:

  COPPER ALLOY

• Center Contact Plating:

  GOLD

• Contact Current(DC)-Max:

  0.025 A

• Contact (DC) Max Rating R Load:

  0.025A@24VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Dielectric Withstand Volts:

  300VAC V

• Electrical Life:

  1000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  GOLD

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Switch Sections:

  4

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
