MCGD018NP03L-TP - MCC

MCGD018NP03L-TP Details

• Manufacturer Part Number:

  MCGD018NP03L-TP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFN3333-D, 8 PIN

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Manufacturer:

  Micro Commercial Components

• YTEOL:

  5

• Avalanche Energy Rating (Eas):

  25 mJ

• Case Connection:

  DRAIN

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  30 V

• Drain Current-Max (ID):

  20 A

• Drain-source On Resistance-Max:

  0.02 Ω

• FET Technology:

  TRENCH MOSFET

• Feedback Cap-Max (Crss):

  60 pF

• JESD-30 Code:

  S-PDSO-N8

• Moisture Sensitivity Level:

  3

• Number of Elements:

  2

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL AND P-CHANNEL

• Power Dissipation-Max (Abs):

  27 W

• Pulsed Drain Current-Max (IDM):

  80 A

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  40

• Transistor Element Material:

  SILICON
