MCIMX6G3CVM05AB - NXP

Description: NXP - MCIMX6G3CVM05AB - MPU, 32BIT, 500MHZ, LFBGA-289

Download MCIMX6G3CVM05AB Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MCIMX6G3CVM05AB - NXP PCB footprint - BGA - BGA - 14x14 mm BGA
click to zoom
3D Models
MCIMX6G3CVM05AB - NXP  - 3D model - BGA - 14x14 mm BGA
click to zoom

MCIMX6G3CVM05AB Details

  • Manufacturer Part Number:

    MCIMX6G3CVM05AB

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    MABGA-289

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    5A992.C

  • HTS Code:

    8542.31.00.01

  • Factory Lead Time:

    13 Weeks

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    10

  • JESD-30 Code:

    S-PBGA-B289

  • Length:

    14 mm

  • Moisture Sensitivity Level:

    3

  • Number of Terminals:

    289

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    LFBGA

  • Package Equivalence Code:

    BGA289,17X17,32

  • Package Shape:

    SQUARE

  • Package Style:

    GRID ARRAY, LOW PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1.32 mm

  • Supply Voltage-Max:

    1.3 V

  • Supply Voltage-Min:

    1.15 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Terminal Finish:

    Nickel/Gold (Ni/Au)

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.8 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    40

  • Width:

    14 mm

  • uPs/uCs/Peripheral ICs Type:

    SoC

MCIMX6G3CVM05AB Frequently Asked Questions (FAQs)

  • The recommended power-on sequence is to power up the VDD_HIGH first, followed by VDD_LOW, and then the core voltage (VDD_CORE). This ensures that the internal voltage regulators are powered up correctly.
  • The clock settings can be configured using the Clock Control Module (CCM) registers. The CCM registers control the clock sources, dividers, and multiplexers. Refer to the i.MX6Dual/6Quad Applications Processor Reference Manual for more information.
  • The maximum operating temperature range for the MCIMX6G3CVM05AB is -40°C to 105°C. However, the recommended operating temperature range is 0°C to 90°C for optimal performance and reliability.
  • Secure boot can be implemented using the High Assurance Boot (HAB) feature. HAB uses a combination of hardware and software mechanisms to ensure the authenticity and integrity of the boot process. Refer to the i.MX6Dual/6Quad Applications Processor Reference Manual and the HAB documentation for more information.
  • The MCIMX6G3CVM05AB can support up to 4GB of RAM. However, the actual amount of RAM that can be used depends on the specific application and the memory configuration.
