MCIMX6Y2DVM05AB - NXP

Description: Microprocessors - MPU i.MX 32-bit MPU, ARM Cortex-A7 core, 528MHz, 289BGA

Download MCIMX6Y2DVM05AB Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MCIMX6Y2DVM05AB - NXP PCB footprint - BGA - BGA - 14 x 14 mm, 0.8 mm pitch, MAPBGA-2894
click to zoom
3D Models
MCIMX6Y2DVM05AB - NXP  - 3D model - BGA - 14 x 14 mm, 0.8 mm pitch, MAPBGA-2894
click to zoom

MCIMX6Y2DVM05AB Details

  • Manufacturer Part Number:

    MCIMX6Y2DVM05AB

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    MAPBGA-289

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    5A992.C

  • HTS Code:

    8542.31.00.01

  • Factory Lead Time:

    13 Weeks

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    9

  • JESD-30 Code:

    S-PBGA-B289

  • JESD-609 Code:

    e1

  • Length:

    14 mm

  • Moisture Sensitivity Level:

    3

  • Number of Terminals:

    289

  • Operating Temperature-Max:

    95 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    LFBGA

  • Package Equivalence Code:

    BGA289,17X17,32

  • Package Shape:

    SQUARE

  • Package Style:

    GRID ARRAY, LOW PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1.32 mm

  • Supply Voltage-Max:

    1.5 V

  • Supply Voltage-Min:

    1.275 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Terminal Finish:

    Nickel/Gold (Ni/Au)

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.8 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    40

  • Width:

    14 mm

  • uPs/uCs/Peripheral ICs Type:

    SoC

MCIMX6Y2DVM05AB Frequently Asked Questions (FAQs)

  • The recommended operating temperature range for the MCIMX6Y2DVM05AB is -40°C to 105°C.
  • The clock settings for the MCIMX6Y2DVM05AB can be configured using the Clock Control Module (CCM) registers. Refer to the i.MX6 Dual/Quad Applications Processor Reference Manual for more information.
  • The maximum frequency of the CPU is 1.2 GHz, and the maximum frequency of the GPU is 532 MHz.
  • The DDR3 memory interface can be enabled by configuring the DDR3 PHY registers and the Memory Controller registers. Refer to the i.MX6 Dual/Quad Applications Processor Reference Manual for more information.
  • The power consumption of the MCIMX6Y2DVM05AB varies depending on the operating frequency and usage scenario. Refer to the i.MX6 Dual/Quad Applications Processor Datasheet for more information on power consumption.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

MCIMX6Y2DVM05AB Overview

Use the download button to access the MCIMX6Y2DVM05AB schematic symbol, PCB footprint, and 3D model.
