MCNDI-04S - Multicomp Pro

MCNDI-04S Details

• Manufacturer Part Number:

  MCNDI-04S

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  SPC Multicomp

• YTEOL:

  6

• Actuator Color:

  WHITE

• Actuator Length:

  0.7 inch

• Actuator Type:

  SLIDE TYPE

• Body Color:

  BLACK

• Body Length or Diameter:

  11.1 mm

• Center Contact Material:

  COPPER ALLOY

• Center Contact Plating:

  GOLD OVER NICKEL

• Contact Current(DC)-Max:

  0.025 A

• Contact (DC) Max Rating R Load:

  .025A@24VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  2000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  GOLD OVER NICKEL

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  THERMOPLASTIC

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Positions:

  8

• Number of Switch Sections:

  4

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• PCB Hole Count:

  8

• Sealing:

  TOP TAPE SEALED

• Solderability:

  REFLOW

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Terminal Finish:

  GOLD

• Termination Type:

  SOLDER
