MCNDP-08V - Multicomp Pro

MCNDP-08V Details

• Manufacturer Part Number:

  MCNDP-08V

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  SPC Multicomp

• YTEOL:

  4.9

• Actuator Type:

  PIANO TYPE

• Body Breadth:

  9.9 mm

• Body Color:

  BLACK

• Body Height:

  10.2 mm

• Body Length or Diameter:

  21.88 mm

• Center Contact Material:

  COPPER ALLOY

• Center Contact Plating:

  GOLD

• Contact Current(DC)-Max:

  0.025 A

• Contact (DC) Max Rating R Load:

  0.025A@24VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  2000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  GOLD

• Housing Material:

  PBT THERMOPLASTIC

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  PA66

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Switch Sections:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PCB Hole Count:

  16

• Solderability:

  HAND

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  PIANO DIP SWITCH

• Terminal Finish:

  Gold (Au)

• Terminal Length:

  0.126 inch

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
