MCP48FEB24-20E/MQ - Microchip

MCP48FEB24-20E/MQ Details

• Manufacturer Part Number:

  MCP48FEB24-20E/MQ

• Part Life Cycle Code:

  Active

• Package Description:

  VQFN-20

• HTS Code:

  8542.39.00.40

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  6.95

• Analog Output Voltage-Max:

  5.484 V

• Analog Output Voltage-Min:

  0.01 V

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  BINARY

• Input Format:

  SERIAL

• JESD-30 Code:

  S-PQCC-N20

• Length:

  5 mm

• Linearity Error-Max (EL):

  0.14648%

• Number of Bits:

  12

• Number of Functions:

  1

• Number of Terminals:

  20

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC20,.20SQ,25

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Seated Height-Max:

  1 mm

• Settling Time-Nom (tstl):

  7.8 µs

• Supply Current-Max:

  3.2 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  QUAD

• Width:

  5 mm
