MCP6C02T-100H/Q8BVAO - Microchip

MCP6C02T-100H/Q8BVAO Details

• Manufacturer Part Number:

  MCP6C02T-100H/Q8BVAO

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Pin Count:

  8

• Manufacturer Package Code:

  VDFN-8

• Country Of Origin:

  Thailand

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Factory Lead Time:

  7 Weeks

• Date Of Intro:

  2019-08-30

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  20

• Amplifier Type:

  OPERATIONAL AMPLIFIER

• Architecture:

  VOLTAGE-FEEDBACK

• Average Bias Current-Max (IIB):

  215 µA

• Bias Current-Max (IIB) @25C:

  215 µA

• Common-mode Reject Ratio-Min:

  138 dB

• Common-mode Reject Ratio-Nom:

  165 dB

• Frequency Compensation:

  YES

• Input Offset Voltage-Max:

  12 µV

• JESD-30 Code:

  S-PDSO-N8

• Length:

  3 mm

• Low-Bias:

  NO

• Low-Offset:

  YES

• Micropower:

  YES

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC8,.12,25

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TR

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Power:

  NO

• Programmable Power:

  NO

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  0.9 mm

• Supply Current-Max:

  0.725 mA

• Supply Voltage Limit-Max:

  5.5 V

• Surface Mount:

  YES

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Unity Gain BW-Nom:

  390

• Voltage Gain-Min:

  100

• Wideband:

  NO

• Width:

  3 mm
