Description:Board Mount Temperature Sensors +/- 1.5C Thermocouple to I2C converter in 5mmx5mm QFN. This device has Opens/Shorts pin detection. This device supports K, J, T, N, S, E, B, and R type thermocouples.
The datasheet provides general guidelines, but for optimal performance, it's recommended to place the MCP9601T-E/MX close to the thermocouple, use a ground plane, and keep the analog and digital traces separate. A 4-layer PCB with a dedicated analog ground plane is recommended.
The MCP9601T-E/MX has an internal cold junction compensation (CJC) circuit, but it may require calibration for high-accuracy applications. Calibration involves measuring the CJC voltage and adjusting the internal voltage reference. Refer to the application note AN2217 for calibration procedures.
The maximum thermocouple wire length depends on the specific application and noise environment. As a general guideline, keep the thermocouple wire length as short as possible (less than 10 feet) and use a shielded, twisted-pair cable to minimize noise pickup. Use a thermocouple wire type that matches the thermocouple type (e.g., K-type, J-type, etc.).
To minimize EMI and RFI, use a shielded enclosure, keep the thermocouple wire and PCB traces as short as possible, and use a common-mode filter (e.g., a ferrite bead) on the thermocouple wires. Ensure the PCB layout follows good EMI/RFI design practices, such as separating analog and digital circuits.
To ensure proper operation, power up the MCP9601T-E/MX in the following sequence: 1) Apply VDD, 2) Apply VREF, and 3) Apply the thermocouple voltage. This sequence helps prevent latch-up and ensures the internal voltage reference is stable.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
MCP9601T-E/MX Overview
Use the download button to access the MCP9601T-E/MX schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like MCP96,
or try a keyword search, such as Other Signal Circuits
About Microchip
Microchip Technology Inc. is a leading manufacturer of microcontrollers and semiconductor devices for a wide range of applications in the aerospace, automotive, consumer electronics, industrial, and medical industries. Alongside a comprehensive product portfolio, Microchip Technology Inc. also provides easy-to-use development tools that enable engineers to create optimal designs quickly with minimal iterations to reduce risk while lowering total system costs to market. Headquartered in Chandler, Arizona, th
