MCP9801T-M/SN - Microchip

MCP9801T-M/SN Details

• Manufacturer Part Number:

  MCP9801T-M/SN

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  0.150 INCH, PLASTIC, MS-012, SOIC-8

• Pin Count:

  8

• Manufacturer Package Code:

  SOIC-8

• Country Of Origin:

  Mainland China, Thailand

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Factory Lead Time:

  7 Weeks

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  9

• Accuracy-Max (Cel):

  3 Cel

• Body Breadth:

  3.9 mm

• Body Height:

  1.72 mm

• Body Length or Diameter:

  4.89 mm

• Housing:

  PLASTIC

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT

• Number of Bits:

  12

• Number of Terminals:

  8

• Operating Current-Max:

  0.2 mA

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Interface Type:

  2-WIRE INTERFACE

• Output Voltage-Min:

  0.4 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOP8,.25

• Package Shape/Style:

  RECTANGULAR

• Sensors/Transducers Type:

  TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  2.7 V

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn)

• Termination Type:

  SOLDER
