The recommended PCB layout for optimal thermal performance involves placing the device on a 2-layer or 4-layer board with a solid ground plane on the bottom layer, and using thermal vias to connect the exposed pad to the ground plane. Additionally, keeping the copper traces wide and short can help to reduce thermal resistance.
To ensure the device is properly biased, make sure to connect the EN pin to a logic high signal (typically 3.3V or 5V) to enable the device. Also, ensure that the input voltage (VIN) is within the recommended range of 2.7V to 5.5V, and that the output voltage (VOUT) is set to the desired value using the FB pin and an external resistor divider.
The maximum output current capability of the MCS1802GS-20-Z is 2A. However, it's recommended to derate the output current based on the ambient temperature and the PCB layout to ensure reliable operation.
To protect the device from overvoltage and undervoltage conditions, consider adding external overvoltage protection (OVP) and undervoltage lockout (UVLO) circuits. These can be implemented using external components such as zener diodes, resistors, and comparators.
The recommended input capacitor type is a ceramic capacitor with a value of 10uF to 22uF. This helps to filter out input noise and ensure stable operation. Make sure to choose a capacitor with a voltage rating that exceeds the maximum input voltage.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
MCS1802GS-20-Z Overview
Use the download button to access the MCS1802GS-20-Z schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like MCS18,
or try a keyword search, such as Other Sensors/Transducers
