MCX-P-P-H-RA-TH1 - SAMTEC

MCX-P-P-H-RA-TH1 Details

• Manufacturer Part Number:

  MCX-P-P-H-RA-TH1

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Factory Lead Time:

  1 Week

• Manufacturer:

  Samtec Inc

• YTEOL:

  7

• Body Breadth:

  0.256 inch

• Body Depth:

  0.417 inch

• Body Length:

  0.236 inch

• Body/Shell Style:

  PLUG

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF MCX CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  Gold (Au)

• Contact Gender:

  MALE

• Contact Material:

  NOT SPECIFIED

• Contact Resistance:

  5 mΩ

• Contact Style:

  COAX

• Coupling Type:

  SNAP

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  1400VAC V

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  POLYTETRAFLUOROETHYLENE

• JESD-609 Code:

  e4

• MIL Conformance:

  NO

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Frequency-Max:

  6 GHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -65 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Shell Material:

  BRASS

• Terminal Length:

  0.118 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1

• VSWR:

  1.5
