MDP1605131AGD04 - Vishay

MDP1605131AGD04 Details

• Manufacturer Part Number:

  MDP1605131AGD04

• Rohs Code:

  No

• Part Life Cycle Code:

  Active

• Package Description:

  DIP

• Reach Compliance Code:

  Not Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8533.21.00.60

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  5.36

• Construction:

  Molded Case

• Element Power Dissipation:

  0.125 W

• First Element Resistance:

  220 Ω

• JESD-609 Code:

  e0

• Lead Length:

  3.3 mm

• Lead Spacing:

  2.54 mm

• Mounting Feature:

  THROUGH HOLE MOUNT

• Network Type:

  TERMINATOR

• Number of Elements:

  2

• Number of Functions:

  14

• Number of Terminals:

  16

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Height:

  3.05 mm

• Package Length:

  6.35 mm

• Package Shape:

  RECTANGULAR PACKAGE

• Package Style:

  DIP

• Package Width:

  21.59 mm

• Packing Method:

  TUBE

• Rated Power Dissipation (P):

  1.92 W

• Rated Temperature:

  70 °C

• Resistor Type:

  ARRAY/NETWORK RESISTOR

• Second/Last Element Resistance:

  330 Ω

• Size Code:

  8525

• Surface Mount:

  NO

• Technology:

  METAL GLAZE/THICK FILM

• Temperature Coefficient:

  100 ppm/°C

• Temperature Coefficient Tracking:

  100 ppm/°C

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Shape:

  FLAT

• Tolerance:

  2%
