MERA-556+ - Mini-Circuits

MERA-556+ Details

• Manufacturer Part Number:

  MERA-556+

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  6 X 4.90 MM, ROHS COMPLIANT, PLASTIC, CASE DL1020, 8 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  Mini-Circuits

• YTEOL:

  6.64

• Additional Feature:

  LOW NOISE

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Gain:

  16 dB

• Input Power-Max (CW):

  13 dBm

• JESD-609 Code:

  e2

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  2

• Number of Terminals:

  8

• Operating Frequency-Max:

  2200 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -45 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOLCC8,.25

• Power Supplies:

  4.9 V

• RF/Microwave Device Type:

  WIDE BAND LOW POWER

• Supply Current-Max:

  65 mA

• Surface Mount:

  YES

• Terminal Finish:

  TIN SILVER NICKEL

• VSWR-Max:

  1.4
