MFP213N-RA - KNITTER-SWITCH

MFP213N-RA Details

• Manufacturer Part Number:

  MFP213N-RA

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.50

• Manufacturer:

  knitter-switch

• Actuator Color:

  BLACK

• Actuator Length:

  0.157 inch

• Actuator Material:

  POLYOXYMETHYLENE

• Actuator Type:

  SLIDE

• Body Breadth:

  4.699 mm

• Body Color:

  NATURAL

• Body Height:

  6.8072 mm

• Body Length or Diameter:

  8.5852 mm

• Center Contact Material:

  PHOSPHOR BRONZE

• Center Contact Plating:

  SILVER

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  0.1A@12VDC

• Contact Resistance:

  0.02 mΩ

• Contact Voltage(DC)-Max:

  12 V

• Dielectric Withstand Volts:

  500VAC V

• End Contact Material:

  PHOSPHOR BRONZE

• End Contact Plating:

  SILVER

• Housing Material:

  STEEL

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  PHENOLIC

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Positions:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• PCB Hole Count:

  6

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Type:

  SLIDE SWITCH

• Terminal Length:

  0.11 inch

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
