MGDD-60-R-I/T - Gaia Converter

MGDD-60-R-I/T Details

• Manufacturer Part Number:

  MGDD-60-R-I/T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-17

• Country Of Origin:

  France

• ECCN Code:

  EAR99

• Manufacturer:

  GAIA Converter Inc

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  91%

• Input Voltage-Max:

  160 V

• Input Voltage-Min:

  12 V

• Input Voltage-Nom:

  28 V

• JESD-30 Code:

  R-MDFM-T17

• JESD-609 Code:

  e4

• Length:

  82.5 mm

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  17

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1.25 A

• Output Voltage-Max:

  26.4 V

• Output Voltage-Min:

  19.2 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  METAL

• Package Code:

  DFM

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Protections:

  INPUT UNDER VOLTAGE; OVER VOLTAGE; OVER CURRENT; THERMAL;SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.18382 Vrms

• Seated Height-Max:

  12.7 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  GOLD OVER NICKEL

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Total Power Output-Max:

  60 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.03 s

• Width:

  48.5 mm
