MGDT100125 - Vishay

MGDT100125 Details

• Manufacturer Part Number:

  MGDT100125

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  5.8

• Application:

  GATE DRIVE

• Height:

  11.43 mm

• Length:

  20.57 mm

• Mounting Feature:

  THROUGH HOLE MOUNTED

• Number of Functions:

  3

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Primary Inductance:

  240 µH

• Surface Mount:

  NO

• Transformer Type:

  PULSE TRANSFORMER

• Turns Ratio (Np:Ns):

  1:1.25:1.25

• Width:

  18.42 mm
