MGJ6D122005LMC-R7 - Murata Electronics

MGJ6D122005LMC-R7 Details

• Manufacturer Part Number:

  MGJ6D122005LMC-R7

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  9

• Additional Feature:

  ADDITIONAL -5V OUTRPUT VOLTAGE ALSO AVAILABLE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  18 V

• Input Voltage-Min:

  9 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-XDMA-B7

• JESD-609 Code:

  e4

• Length:

  39.98 mm

• Load Regulation-Max:

  10%

• Moisture Sensitivity Level:

  2

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  7

• Operating Temperature-Max:

  90 °C

• Output Voltage-Max:

  20.6 V

• Output Voltage-Min:

  19.4 V

• Output Voltage-Nom:

  20 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  245

• Seated Height-Max:

  9.85 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Terminal Form:

  BU

• Terminal Position:

  DUAL

• Total Power Output-Max:

  4.8 W

• Trim/Adjustable Output:

  NO

• Width:

  27.81 mm
