MGJ6D241510DC - Murata Electronics

MGJ6D241510DC Details

• Manufacturer Part Number:

  MGJ6D241510DC

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DIP-7

• ECCN Code:

  EAR99

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  7

• Additional Feature:

  -10V ADDITIONAL OUTPUT AVAILABLE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  AAMI, ANSI, C-UL-US, EN, ES, IEC, UL

• Efficiency (Main Output):

  82%

• Input Voltage-Max:

  36 V

• Input Voltage-Min:

  18 V

• Input Voltage-Nom:

  24 V

• JESD-30 Code:

  R-PDIP-T7

• Length:

  45.47 mm

• Line Regulation-Max:

  2%

• Load Regulation-Max:

  10%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  7

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.24 A

• Output Voltage-Max:

  15.45 V

• Output Voltage-Min:

  14.55 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP7,1.6(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Protections:

  OVER LOAD, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.0707 Vrms

• Screening Level:

  2MOPP

• Seated Height-Max:

  10.63 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Total Power Output-Max:

  3.6 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.015 s

• Width:

  27.81 mm
