MGJ6T05150505MC-R7 - Murata Electronics

MGJ6T05150505MC-R7 Details

• Manufacturer Part Number:

  MGJ6T05150505MC-R7

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Package Description:

  PACKAGE-7

• ECCN Code:

  EAR99

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  1

• Additional Feature:

  FOR IGBT OUTPUT2 VOLTGE IS -10V, FOR SIC 20/-5V, FOR MOSFET 15/-5V

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  UL, ANSI, AAMI

• Efficiency (Main Output):

  72%

• Input Voltage-Max:

  9 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-XXMA-X7

• Length:

  31.24 mm

• Line Regulation-Max:

  2%

• Load Regulation-Max:

  10%

• Moisture Sensitivity Level:

  2

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  7

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.24 A

• Output Voltage-Max:

  15.6 V

• Output Voltage-Min:

  14.4 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  SHORT CIRCUIT; OVER LOAD

• Ripple Voltage (Main Out):

  0.0707 Vrms

• Screening Level:

  IEC 60601-1, One MOPP, IEC 60601-1, Two MOOP

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  6 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.015 s

• Width:

  22.61 mm
