MGN1D120603MC-R7 - Murata Electronics

MGN1D120603MC-R7 Details

• Manufacturer Part Number:

  MGN1D120603MC-R7

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  9

• Additional Feature:

  ALSO -3V VOUT AVAILABLE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  UL

• Efficiency (Main Output):

  68.5%

• Input Voltage-Max:

  13.2 V

• Input Voltage-Min:

  10.8 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-XDMA-N12

• JESD-609 Code:

  e4

• Length:

  16 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  1%

• Moisture Sensitivity Level:

  2

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  12

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.111 A

• Output Voltage-Max:

  6.3 V

• Output Voltage-Min:

  5.88 V

• Output Voltage-Nom:

  6 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  260

• Protections:

  SHORT CIRCUIT; REVERSE POLARITY

• Ripple Voltage (Main Out):

  0.017675 Vrms

• Screening Level:

  UL 62368-1

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Finish:

  Gold (Au)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  1.25 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  1 W

• Trim/Adjustable Output:

  NO

• Width:

  12 mm
