Cosel recommends a multi-layer PCB with a large ground plane and thermal vias to dissipate heat. A minimum of 2oz copper thickness is recommended. Ensure good airflow around the module and consider adding a heat sink or thermal interface material for high-power applications.
Follow proper PCB design and layout guidelines, use a metal enclosure, and ensure proper grounding and shielding. Additionally, consider adding EMI filters or common-mode chokes to the input and output lines to minimize emissions and susceptibility.
Derating curves are available upon request from Cosel USA Inc. Apply the derating curves by reducing the output power or input voltage according to the specified temperature and altitude conditions to ensure reliable operation.
Yes, the MGS302412 can be used in redundant or parallel configurations. However, it's essential to follow Cosel's guidelines for synchronization, current sharing, and fault tolerance to ensure reliable operation and minimize the risk of damage or failure.
The MGS302412 meets various agency approvals and certifications, including UL60950-1, EN60950-1, and IEC60950-1. Additionally, it complies with RoHS and REACH directives. Contact Cosel USA Inc for specific certification documents and compliance information.
