MH11063-H1 - Foxconn

MH11063-H1 Details

• Manufacturer Part Number:

  MH11063-H1

• Part Life Cycle Code:

  Obsolete

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.20

• Manufacturer:

  Foxconn Interconnect Technology Limited

• YTEOL:

  0

• Board Mounting Option:

  SPLIT BOARD LOCK

• Body Breadth:

  0.512 inch

• Body Depth:

  0.504 inch

• Body Length:

  0.551 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  MINI DIN CONNECTOR

• Contact Finish Mating:

  AU

• Contact Gender:

  FEMALE

• Contact Material:

  COPPER ALLOY

• Contact Resistance:

  30 mΩ

• Contact Style:

  RND PIN-SKT

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  750VAC V

• Durability:

  500 Cycles

• EMI Shielded:

  NO

• IEC Conformance:

  NO

• Insertion Force-Max:

  44.48 N

• Insulation Resistance:

  1000000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYETHYLENE

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• Plating Thickness:

  30u inch

• Polarization Key:

  POLARIZED

• Rated Current (Signal):

  2 A

• Reference Standard:

  UL

• Shell Material:

  COPPER ALLOY

• Terminal Length:

  0.125 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  6

• Withdrawl Force-Min:

  8.896 N
