MHPS4284 Details

• Manufacturer Part Number:

  MHPS4284

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  UK

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  APEM Inc

• YTEOL:

  7

• Actuator Length:

  0.335 inch

• Actuator Type:

  PUSHBUTTON

• Body Breadth:

  8.5 mm

• Body Height:

  8.5 mm

• Body Length or Diameter:

  13 mm

• Center Contact Material:

  PHOSPHOR BRONZE

• Center Contact Plating:

  SILVER

• Circuit Configuration:

  1X1

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  .1A@30VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  30 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  10000 Cycle(s)

• Insulation Resistance:

  100000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Switches:

  1

• Operating Force-Max:

  2.75 N

• Operating Temperature-Max:

  65 °C

• Operating Temperature-Min:

  -20 °C

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  4PDT

• Switch Type:

  KEYPAD SWITCH

• Terminal Finish:

  Silver (Ag)

• Terminal Length:

  0.138 inch

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
