MIC4467CN - Rochester Electronics

MIC4467CN Details

• Manufacturer Part Number:

  MIC4467CN

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  DIP

• Package Description:

  PLASTIC, DIP-14

• Pin Count:

  14

• Reach Compliance Code:

  Unknown

• Manufacturer:

  Rochester Electronics LLC

• High Side Driver:

  NO

• Interface IC Type:

  NAND GATE BASED MOSFET DRIVER

• JESD-30 Code:

  R-PDIP-T14

• JESD-609 Code:

  e0

• Moisture Sensitivity Level:

  NOT SPECIFIED

• Number of Functions:

  4

• Number of Terminals:

  14

• Operating Temperature-Max:

  70 °C

• Output Peak Current Limit-Nom:

  1.2 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  240

• Qualification Status:

  COMMERCIAL

• Seated Height-Max:

  5.588 mm

• Supply Voltage-Max:

  18 V

• Supply Voltage-Min:

  4.5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Turn-off Time:

  0.1 µs

• Turn-on Time:

  0.1 µs

• Width:

  7.62 mm
