MIC5387-SG4YMT-TR - Microchip

MIC5387-SG4YMT-TR Details

• Manufacturer Part Number:

  MIC5387-SG4YMT-TR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  1.60 X 1.60 MM, GREEN, MLF-6

• Pin Count:

  6

• Manufacturer Package Code:

  UDFN-6

• Country Of Origin:

  Mainland China, Malaysia

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  8

• Adjustability:

  FIXED

• Dropout Voltage1-Max:

  0.31 V

• Dropout Voltage1-Nom:

  0.18 V

• Dropout Voltage2-Max:

  0.38 V

• Input Voltage Absolute-Max:

  6 V

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  2.5 V

• JESD-30 Code:

  S-XDSO-N6

• JESD-609 Code:

  e4

• Length:

  1.6 mm

• Line Regulation-Max:

  0.0099%

• Load Regulation-Max:

  0.02145%

• Number of Functions:

  1

• Number of Outputs:

  3

• Number of Terminals:

  6

• Operating Temperature TJ-Max:

  125 °C

• Operating Temperature TJ-Min:

  -40 °C

• Output Current1-Max:

  0.15 A

• Output Current2-Max:

  0.15 A

• Output Voltage1-Max:

  3.399 V

• Output Voltage1-Min:

  3.201 V

• Output Voltage1-Nom:

  3.3 V

• Output Voltage2-Max:

  1.854 V

• Output Voltage2-Min:

  1.746 V

• Output Voltage2-Nom:

  1.8 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC6,.047,20

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TR

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Regulator Type:

  FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  0.6 mm

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  40

• Voltage Tolerance-Max:

  3%

• Width:

  1.6 mm
