MIMXRT1052DVJ6B - NXP

MIMXRT1052DVJ6B Details

• Manufacturer Part Number:

  MIMXRT1052DVJ6B

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  MAPBGA-196

• Country Of Origin:

  Mainland China

• ECCN Code:

  5A992.C

• HTS Code:

  8542.31.00.30

• Factory Lead Time:

  13 Weeks

• Date Of Intro:

  2018-09-12

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  6

• Bit Size:

  32

• Boundary Scan:

  YES

• Clock Frequency-Max:

  24 MHz

• Format:

  FLOATING-POINT

• Integrated Cache:

  YES

• JESD-30 Code:

  S-PBGA-B196

• JESD-609 Code:

  e2

• Length:

  12 mm

• Low Power Mode:

  YES

• Moisture Sensitivity Level:

  3

• Number of DMA Channels:

  32

• Number of Serial I/Os:

  29

• Number of Terminals:

  196

• On Chip Data RAM Width:

  8

• Operating Temperature-Max:

  95 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LFBGA

• Package Equivalence Code:

  BGA196,14X14,32

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, LOW PROFILE, FINE PITCH

• Peak Reflow Temperature (Cel):

  260

• RAM (words):

  524288

• Screening Level:

  TS 16949

• Seated Height-Max:

  1.52 mm

• Speed:

  600 MHz

• Supply Current-Max:

  105 mA

• Supply Voltage-Max:

  1.3 V

• Supply Voltage-Min:

  1.25 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  OTHER

• Terminal Finish:

  Tin/Silver (Sn/Ag)

• Terminal Form:

  BALL

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  40

• Width:

  12 mm

• uPs/uCs/Peripheral ICs Type:

  SoC
