MKWI80-48S48-HS - Minmax

MKWI80-48S48-HS Details

• Manufacturer Part Number:

  MKWI80-48S48-HS

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-6

• ECCN Code:

  EAR99

• Manufacturer:

  Minmax Technology Co Ltd

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  C-UL-US, CB, CE, CUL, EN, IEC, UL

• Efficiency (Main Output):

  92%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  18 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-MDMA-P6

• Length:

  50.8 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.3%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  65 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1.67 A

• Output Voltage-Max:

  52.8 V

• Output Voltage-Min:

  43.2 V

• Output Voltage-Nom:

  48 V

• Package Body Material:

  METAL

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,6LEAD,1.8

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER LOAD, OVER TEMPERATURE, SHORT CIRCUIT, UNDER VOLTAGE

• Ripple Voltage (Main Out):

  0.10605 Vrms

• Screening Level:

  EN/IEC/UL 62368-1

• Seated Height-Max:

  11.75 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  80 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.05 s

• Width:

  25.4 mm
