MLL1200S - TE Connectivity

MLL1200S Details

• Manufacturer Part Number:

  MLL1200S

• Brand Name:

  Alcoswitch

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.50

• Factory Lead Time:

  15 Weeks

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Actuator Angle:

  90 deg

• Actuator Color:

  BLACK

• Actuator Length:

  0.059 inch

• Actuator Material:

  NYLON

• Actuator Type:

  SIDE TYPE

• Body Breadth:

  2.6 mm

• Body Color:

  BLACK

• Body Height:

  1.4 mm

• Body Length or Diameter:

  6.7 mm

• Center Contact Material:

  COPPER ALLOY

• Center Contact Plating:

  SILVER OVER NICKEL

• Contact Current(DC)-Max:

  0.3 A

• Contact (DC) Max Rating R Load:

  .3A@4VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  4 V

• Dielectric Withstand Volts:

  100VAC V

• Electrical Life:

  10000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  SILVER OVER NICKEL

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Positions:

  2

• Operating Force-Max:

  2.7 N

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Sealing:

  EPOXY TERMINAL SEALED

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPDT

• Switch Type:

  SLIDE SWITCH

• Terminal Finish:

  Silver (Ag)

• Terminal Material:

  COPPER ALLOY

• Termination Type:

  SOLDER
