MM50M21G3IS - Radiall

MM50M21G3IS Details

• Manufacturer Part Number:

  MM50M21G3IS

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Radiall

• Board Mounting Option:

  HOLE .086-.098

• Body Breadth:

  0.391 inch

• Body Depth:

  0.242 inch

• Body Length:

  1.63 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  RECTANGULAR CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  NOT APPLICABLE

• Contact Gender:

  MALE

• Contact Material:

  NOT SPECIFIED

• Contact Pattern:

  STAGGERED

• Contact Resistance:

  5 mΩ

• Contact Style:

  RND PIN-SKT

• DIN Conformance:

  NO

• Durability:

  500 Cycles

• IEC Conformance:

  NO

• Insulation Resistance:

  5000000000 Ω

• Insulator Material:

  GLASS FILLED DIALLYL PHTHALATE

• MIL Conformance:

  NO

• Mating Contact Pitch:

  0.094 inch

• Mating Contact Row Spacing:

  0.09 inch

• Mounting Option 1:

  GUIDE PIN

• Mounting Option 2:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  4

• Number of Rows Loaded:

  4

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  2.286 mm

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  5 A

• Terminal Length:

  0.175 inch

• Terminal Pitch:

  2.3876 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  50
