MM74C922N - Rochester Electronics

MM74C922N Details

• Manufacturer Part Number:

  MM74C922N

• Part Life Cycle Code:

  Obsolete

• Package Description:

  0.300 INCH, PLASTIC, MS-001, DIP-18

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Rochester Electronics LLC

• YTEOL:

  0

• Additional Feature:

  16 KEY ENCODERS

• Family:

  CMOS

• JESD-30 Code:

  R-PDIP-T18

• JESD-609 Code:

  e3

• Length:

  22.73 mm

• Logic IC Type:

  ENCODER

• Number of Bits:

  8

• Number of Functions:

  1

• Number of Terminals:

  18

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP18,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Power Supply Current-Max (ICC):

  2.6 mA

• Propagation Delay (tpd):

  150 ns

• Seated Height-Max:

  5.33 mm

• Supply Voltage-Max (Vsup):

  15 V

• Supply Voltage-Min (Vsup):

  3 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  MATTE TIN

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Width:

  7.62 mm
