MM74C922WM - onsemi

Description: 20-key encoder, SOIC-20

Download MM74C922WM Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MM74C922WM - onsemi PCB footprint - Small Outline Packages - Small Outline Packages - M20B (SOIC)
click to zoom
3D Models
MM74C922WM - onsemi  - 3D model - Small Outline Packages - M20B (SOIC)
click to zoom

MM74C922WM Details

  • Manufacturer Part Number:

    MM74C922WM

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    SOIC-20

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    onsemi

  • YTEOL:

    0

  • Additional Feature:

    20 KEY ENCODER

  • Family:

    74

  • JESD-30 Code:

    R-PDSO-G20

  • Length:

    12.8 mm

  • Load Capacitance (CL):

    50 pF

  • Logic IC Type:

    ENCODER

  • Number of Bits:

    9

  • Number of Functions:

    1

  • Number of Terminals:

    20

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Characteristics:

    3-STATE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP20,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Power Supply Current-Max (ICC):

    2.6 mA

  • Propagation Delay (tpd):

    150 ns

  • Seated Height-Max:

    2.65 mm

  • Supply Voltage-Max (Vsup):

    15 V

  • Supply Voltage-Min (Vsup):

    3 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Width:

    7.5 mm
