MM8430-2610RA1 - Murata Electronics

MM8430-2610RA1 Details

• Manufacturer Part Number:

  MM8430-2610RA1

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  0

• Additional Feature:

  VSWR MAX AT 3 GHZ

• Body Breadth:

  0.134 inch

• Body Depth:

  0.059 inch

• Body Length:

  0.134 inch

• Body/Shell Style:

  RECEPTACLE

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Resistance:

  50 mΩ

• Contact Style:

  COAX

• Coupling Type:

  SNAP

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  450VAC V

• Durability:

  500 Cycles

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Force-Max:

  19.5712 N

• Insertion Loss:

  0.1 dB

• Insulation Resistance:

  500000000 Ω

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Frequency-Max:

  6 GHz

• Operating Temperature-Max:

  90 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  1

• VSWR:

  1.2

• Withdrawl Force-Min:

  4.8928 N
