MMA-212734D-M5 - CML Micro

Description: RF Amplifier IC General Purpose 21GHz ~ 27GHz 32-QFN (5x5)

Download MMA-212734D-M5 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
MMA-212734D-M5 - CML Micro PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 32-Pin QFN
click to zoom
3D Models
MMA-212734D-M5 - CML Micro  - 3D model - Quad Flat No-Lead - 32-Pin QFN
click to zoom

MMA-212734D-M5 Details

  • Manufacturer Part Number:

    MMA-212734D-M5

  • Part Life Cycle Code:

    Active

  • Package Description:

    QFN-32

  • Manufacturer:

    CML Microcircuits Plc

  • YTEOL:

    8

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Gain:

    24 dB

  • Input Power-Max (CW):

    20 dBm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Functions:

    1

  • Number of Terminals:

    32

  • Operating Frequency-Max:

    27000 MHz

  • Operating Frequency-Min:

    21000 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Equivalence Code:

    LCC32,.2SQ,20

  • Power Supplies:

    6 V

  • RF/Microwave Device Type:

    POWER AMPLIFIER

  • Surface Mount:

    YES

  • Technology:

    GAAS

  • VSWR-Max:

    1.43
