MNA-4+ - Mini-Circuits

MNA-4+ Details

• Manufacturer Part Number:

  MNA-4+

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  0.120 X 0.120 INCH, ROHS COMPLIANT, PLASTIC, MICRO-MINIATURE, MCLP, CASE DQ849, 8 PIN

• Manufacturer:

  Mini-Circuits

• YTEOL:

  0

• Additional Feature:

  LOW NOISE

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Gain:

  14 dB

• Input Power-Max (CW):

  10 dBm

• JESD-609 Code:

  e2

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Frequency-Max:

  2500 MHz

• Operating Frequency-Min:

  500 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  LCC8,.12SQ,25

• Power Supplies:

  2.8/5 V

• RF/Microwave Device Type:

  WIDE BAND LOW POWER

• Supply Current-Max:

  90 mA

• Surface Mount:

  YES

• Technology:

  GAAS

• Terminal Finish:

  Tin/Silver/Nickel (Sn/Ag/Ni)

• VSWR-Max:

  1.7
