MP8801DJ-2.5 - Monolithic Power Systems (MPS)

MP8801DJ-2.5 Details

• Manufacturer Part Number:

  MP8801DJ-2.5

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  TSOT

• Pin Count:

  6

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Monolithic Power Systems

• YTEOL:

  5

• Dropout Voltage1-Nom:

  0.5 V

• Input Voltage-Max:

  6.5 V

• Input Voltage-Min:

  2.7 V

• JESD-30 Code:

  R-PDSO-G5

• Length:

  2.9 mm

• Load Regulation-Max(%):

  0.003725%

• Number of Functions:

  1

• Number of Terminals:

  5

• Operating Temperature TJ-Max:

  150 °C

• Output Current1-Max:

  0.15 A

• Output Voltage1-Max:

  2.55 V

• Output Voltage1-Min:

  2.45 V

• Output Voltage1-Nom:

  2.5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VSSOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH

• Qualification Status:

  Not Qualified

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  1 mm

• Surface Mount:

  YES

• Technology:

  PMOS

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.95 mm

• Terminal Position:

  DUAL

• Voltage Tolerance-Max:

  2%

• Width:

  1.6 mm
