MPBS-42H01(L)-F14 - KNITTER-SWITCH

MPBS-42H01(L)-F14 Details

• Manufacturer Part Number:

  MPBS-42H01(L)-F14

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  knitter-switch

• Actuator Length:

  0.543 inch

• Actuator Travel:

  4.7498 mm

• Actuator Type:

  PUSHBUTTON

• Additional Feature:

  ROHS COMPLIANT

• Body Breadth:

  9.4996 mm

• Body Height:

  35.9918 mm

• Body Length or Diameter:

  10.0076 mm

• Contact (AC) Max Rating R Load:

  0.2A@250VAC

• Contact Current(AC)-Max:

  0.2 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@25VDC

• Contact Resistance:

  0.006 mΩ

• Contact Timing:

  BREAK-BEFORE-MAKE

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  25 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  100000 Cycle(s)

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• PCB Hole Count:

  20

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  4PDT

• Termination Type:

  SOLDER
