MPC8248VRPIEA - NXP

MPC8248VRPIEA Details

• Manufacturer Part Number:

  MPC8248VRPIEA

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Country Of Origin:

  Malaysia

• ECCN Code:

  5A002.A.1

• HTS Code:

  8542.31.00.01

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  0

• Has ADC:

  NO

• Address Bus Width:

  30

• Bit Size:

  32

• Clock Frequency-Max:

  66.7 MHz

• DMA Channels:

  YES

• External Data Bus Width:

  64

• JESD-30 Code:

  S-PBGA-B516

• JESD-609 Code:

  e2

• Length:

  27 mm

• Moisture Sensitivity Level:

  3

• Number of I/O Lines:

  57

• Number of Terminals:

  516

• Operating Temperature-Max:

  70 °C

• PWM Channels:

  NO

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Equivalence Code:

  BGA516,26X26,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Peak Reflow Temperature (Cel):

  245

• Qualification Status:

  Not Qualified

• Speed:

  300 MHz

• Supply Voltage-Max:

  1.575 V

• Supply Voltage-Min:

  1.425 V

• Supply Voltage-Nom:

  1.5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Nickel/Gold (Ni/Au)

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  27 mm

• uPs/uCs/Peripheral ICs Type:

  MICROPROCESSOR, RISC
