MPL-AY1265-8R2 - Monolithic Power Systems (MPS)

MPL-AY1265-8R2 Details

• Manufacturer Part Number:

  MPL-AY1265-8R2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  23 Weeks

• Manufacturer:

  Monolithic Power Systems

• YTEOL:

  6.6

• Case/Size Code:

  5350

• Construction:

  Rectangular

• DC Resistance:

  0.0125 Ω

• Inductance-Nom (L):

  8.2 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  155 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  6.2 mm

• Package Length:

  13.5 mm

• Package Style:

  SMT

• Package Width:

  12.6 mm

• Packing Method:

  TR

• Rated Current-Max:

  11.5 A

• Self Resonance Frequency:

  7 MHz

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Special Feature:

  INDUCTANCE IS MEASURED AT 100 MILLI AMPERE

• Surface Mount:

  YES

• Terminal Placement:

  DUAL ENDED

• Terminal Shape:

  WRAPAROUND

• Test Frequency:

  0.1 MHz
