MPM12-500P - Advanced Energy

MPM12-500P Details

• Manufacturer Part Number:

  MPM12-500P

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  Module-3

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Advanced Energy Industries Inc

• YTEOL:

  5

• Additional Feature:

  SEATED HEIGHT-NOM

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  12 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  S-XXMA-P3

• Length:

  38.1 mm

• Load Regulation-Max:

  20%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -10 °C

• Output Voltage-Max:

  500 V

• Output Voltage-Min:

  84 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Shape:

  SQUARE

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Seated Height-Max:

  20.1 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UNSPECIFIED

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  1.5 W

• Trim/Adjustable Output:

  NO

• Width:

  38.1 mm
