MPM1220SJ - Tamura

MPM1220SJ Details

• Manufacturer Part Number:

  MPM1220SJ

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-14

• ECCN Code:

  EAR99

• Manufacturer:

  Tamura Corporation of America

• YTEOL:

  8

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  86%

• Input Voltage-Max:

  420 V

• Input Voltage-Min:

  100 V

• Input Voltage-Nom:

  140 V

• JESD-30 Code:

  R-XDMA-T14

• Length:

  40.6 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  14

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -20 °C

• Output Current-Max:

  2 A

• Output Voltage-Max:

  12.6 V

• Output Voltage-Min:

  11.4 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,14LEAD,.7

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT; OVER TEMPERATURE; OVER VOLTAGE

• Ripple Voltage (Main Out):

  0.053 Vrms

• Seated Height-Max:

  24.1 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Total Power Output-Max:

  25 W

• Trim/Adjustable Output:

  NO

• Width:

  31.7 mm
