MPM3550EGLE - Monolithic Power Systems (MPS)

MPM3550EGLE Details

• Manufacturer Part Number:

  MPM3550EGLE

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LGA-18

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  24 Weeks

• Date Of Intro:

  2019-07-25

• Manufacturer:

  Monolithic Power Systems

• YTEOL:

  8

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Mode:

  VOLTAGE-MODE

• Input Voltage-Max:

  36 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  24 V

• JESD-30 Code:

  S-XBGA-N18

• Length:

  12 mm

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Terminals:

  18

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  5 A

• Output Voltage-Max:

  12 V

• Output Voltage-Min:

  1 V

• Output Voltage-Nom:

  3.3 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  LGA

• Package Equivalence Code:

  LGA18(UNSPEC)

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Seated Height-Max:

  3.97 mm

• Supply Current-Max (Isup):

  2000 mA

• Surface Mount:

  YES

• Switcher Configuration:

  BUCK

• Switching Frequency-Max:

  557 kHz

• Technology:

  HYBRID

• Terminal Form:

  NO LEAD

• Terminal Position:

  BOTTOM

• Width:

  12 mm
