MPS0117V2NBC - Murata Electronics

MPS0117V2NBC Details

• Manufacturer Part Number:

  MPS0117V2NBC

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  1/16 BRICK PACKAGE-6

• ECCN Code:

  EAR99

• Factory Lead Time:

  36 Weeks

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, CSA, IEC, UKCA, UL

• Efficiency (Main Output):

  95%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  36 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XDMA-P6

• Length:

  33.02 mm

• Line Regulation-Max:

  0.25%

• Load Regulation-Max:

  0.25%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  17 A

• Output Voltage-Max:

  13.2 V

• Output Voltage-Min:

  9.6 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,6LEAD,1.1

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; SHORT CIRCUIT; THERMAL

• Ripple Voltage (Main Out):

  0.04949 Vrms

• Screening Level:

  IEC/UL 62368-1

• Seated Height-Max:

  13.2 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  7.62 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  204 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.07 s

• Width:

  22.86 mm
