MPU-9150 - TDK

MPU-9150 Details

• Manufacturer Part Number:

  MPU-9150

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  LGA-24

• HTS Code:

  8542.39.00.01

• Manufacturer:

  TDK Corporation

• YTEOL:

  0

• Analog IC - Other Type:

  ANALOG CIRCUIT

• JESD-30 Code:

  S-PBCC-B24

• Length:

  4 mm

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Terminals:

  24

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BCC

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  1.1 mm

• Supply Voltage-Max (Vsup):

  3.465 V

• Supply Voltage-Min (Vsup):

  2.375 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  BUTT

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Width:

  4 mm
