MPX4250AP - Motorola

MPX4250AP Details

• Manufacturer Part Number:

  MPX4250AP

• Part Life Cycle Code:

  Transferred

• Package Description:

  PLASTIC, UNIBODY PACKAGE-6

• Manufacturer:

  Motorola Semiconductor Products

• Accuracy-Max (%):

  1.5%

• Additional Feature:

  TEMPERATURE COMPENSATED, SIGNAL CONDITIONED

• Body Breadth:

  8 mm

• Body Height:

  28.7 mm

• Body Length or Diameter:

  29.46 mm

• Housing:

  PLASTIC

• Linearity (%):

  1.5 %

• Mounting Feature:

  THROUGH HOLE MOUNT

• Offset-Nom:

  0.20V

• Operating Current-Max:

  10 mA

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Range:

  0.20-4.90V

• Output Type:

  ANALOG VOLTAGE

• Port Type:

  BARBED

• Pressure Range-Max:

  36.25 Psi

• Pressure Range-Min:

  2.9 Psi

• Pressure Sensing Mode:

  ABSOLUTE

• Response Time:

  1000 µs

• Sensors/Transducers Type:

  PRESSURE SENSOR,PIEZORESISTIVE

• Supply Voltage-Max:

  5.35 V

• Supply Voltage-Min:

  4.85 V

• Surface Mount:

  NO

• Termination Type:

  SOLDER
