MPX5700ASX - STMicroelectronics

MPX5700ASX Details

• Manufacturer Part Number:

  MPX5700ASX

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PLASTIC, UNBODY PACKAGE-6

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  STMicroelectronics

• YTEOL:

  6

• Accuracy-Max (%):

  2.5%

• Additional Feature:

  TEMPERATURE COMPENSATED, SIGNAL CONDITION

• Body Breadth:

  16.25 mm

• Body Height:

  19.05 mm

• Body Length or Diameter:

  27.94 mm

• Housing:

  PLASTIC

• Linearity (%):

  2.5 %

• Mounting Feature:

  THROUGH HOLE MOUNT

• Offset-Nom:

  0.20V

• Operating Current-Max:

  10 mA

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Range:

  0.20-4.70V

• Output Type:

  ANALOG VOLTAGE

• Port Type:

  BARBED

• Pressure Range-Max:

  101.5 Psi

• Pressure Range-Min:

  2.18 Psi

• Pressure Sensing Mode:

  ABSOLUTE

• Response Time:

  1000 µs

• Sensors/Transducers Type:

  PRESSURE SENSOR,PIEZORESISTIVE

• Supply Voltage-Max:

  5.25 V

• Supply Voltage-Min:

  4.75 V

• Surface Mount:

  NO

• Termination Type:

  SOLDER
