MPY-16HJ - TRW

Description: MULTIPLIER, 64 Pin, Ceramic, DIP

Download MPY-16HJ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MPY-16HJ - TRW - PCB symbol
click to zoom
PCB Footprints
MPY-16HJ - TRW PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - 64-PIN DIP
click to zoom
3D Models
MPY-16HJ - TRW - 3D model - Dual-In-Line Packages - 64-PIN DIP
click to zoom

MPY-16HJ Details

  • Manufacturer Part Number:

    MPY-16HJ

  • Rohs Code:

    No

  • Part Life Cycle Code:

    Transferred

  • Package Description:

    DIP, DIP64,.9

  • Reach Compliance Code:

    Unknown

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    TRW Inc

  • JESD-30 Code:

    R-CDIP-T64

  • JESD-609 Code:

    e0

  • Number of Terminals:

    64

  • Operating Temperature-Max:

    70 °C

  • Package Body Material:

    CERAMIC, METAL-SEALED COFIRED

  • Package Code:

    DIP

  • Package Equivalence Code:

    DIP64,.9

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Qualification Status:

    Not Qualified

  • Supply Voltage-Nom:

    5 V

  • Surface Mount:

    NO

  • Technology:

    BIPOLAR

  • Temperature Grade:

    COMMERCIAL

  • Terminal Finish:

    Tin/Lead (Sn/Pb)

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • uPs/uCs/Peripheral ICs Type:

    DSP PERIPHERAL, MULTIPLIER
