MRJ11204 - TE Connectivity

MRJ11204 Details

• Manufacturer Part Number:

  MRJ11204

• Brand Name:

  Alcoswitch

• Pbfree Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.20

• Factory Lead Time:

  32 Weeks, 2 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  6

• Actuator Type:

  LONG THIN KNOB

• Body Height:

  11 mm

• Body Length or Diameter:

  12.7 mm

• Center Contact Plating:

  GOLD OVER NICKEL

• Contact (AC) Max Rating R Load:

  .02A@20VAC

• Contact Current(AC)-Max:

  0.4 A

• Contact Current(DC)-Max:

  0.4 A

• Contact (DC) Max Rating R Load:

  .02A@20VDC

• Contact Voltage(AC)-Max:

  20 V

• Contact Voltage(DC)-Max:

  20 V

• Electrical Life:

  10000 Cycle(s)

• End Contact Material:

  BRASS

• End Contact Plating:

  GOLD OVER NICKEL

• Housing Material:

  PLASTIC

• Indexing Angle:

  30 deg

• JESD-609 Code:

  e3

• Mounting Feature:

  PANEL MOUNT

• Number of Positions:

  12

• Number of Switch Sections:

  12

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Packing Method:

  BAG; BOX

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SP12T

• Switch Type:

  ROTARY SWITCH

• Terminal Finish:

  Tin (Sn)

• Termination Type:

  SOLDER AND WIRE
