MRJE3404 - TE Connectivity

MRJE3404 Details

• Manufacturer Part Number:

  MRJE3404

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.20

• Factory Lead Time:

  23 Weeks, 5 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  7

• Actuator Type:

  LONG THIN KNOB

• Body Height:

  7.62 mm

• Body Length or Diameter:

  12.37 mm

• Center Contact Plating:

  GOLD OVER NICKEL

• Contact (AC) Max Rating R Load:

  .02A@20VAC

• Contact Current(AC)-Max:

  0.4 A

• Contact Current(DC)-Max:

  0.4 A

• Contact (DC) Max Rating R Load:

  .02A@20VDC

• Contact Voltage(AC)-Max:

  20 V

• Contact Voltage(DC)-Max:

  20 V

• Electrical Life:

  10000 Cycle(s)

• End Contact Material:

  BRASS

• End Contact Plating:

  GOLD OVER NICKEL

• Housing Material:

  PLASTIC

• Indexing Angle:

  15 deg

• Mounting Feature:

  PANEL MOUNT

• Number of Positions:

  4

• Number of Switch Sections:

  4

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  3P4T

• Switch Type:

  ROTARY SWITCH

• Termination Type:

  SOLDER AND WIRE
